Ceiling PVC panel impact-resistanthygienicmoisture-resistant
Add to favorites
Compare this product
Characteristics
- Applications
- for ceiling
- Technical characteristics
- moisture-resistant, impact-resistant, hygienic
- Material
- aluminum, PVC
- Color
- white
- Market
- for healthcare facility, for hospital
- Other characteristics
- easy to install
- Thickness
7 mm, 8 mm, 9.5 mm
(0.276 in, 0.315 in, 0.374 in)- Width
30 mm, 60 mm
(1 in, 2 in)- Length
30 mm, 60 mm, 120 mm
(1.18 in, 2.36 in, 4.72 in)
Description
Overview
PANHYGIENIC Hygienic Board is a gypsum ceiling panel with an antibacterial Bio Proof PVC front coating and an aluminum foil rear coating. Designed for suspended plaster ceilings, the combination improves hygiene, cleaning ease and moisture resistance for controlled environments.
Key benefits
Applications / Usage Areas
Models & description
Panhygienic Antibacterial Gypsum Panel: front surface coated with Bio Proof PVC for antibacterial performance and simplified cleaning; rear side laminated with aluminum foil to enhance moisture resistance. Panels are compatible with T-24 white main and cross carriers and supplied in several size and thickness options.
Delivery Details (table)
THICKNESS | PACKAGE QUANTITY | QUANTITY OF PALLET | VOLUME | PACKAGE WEIGHT | PALLET WEIGHT | 20 DC (24 Ton) | TIR (26 ton)
7mm | 12 pcs = 4.32 m² | 68 packs = 293.76 m² | 0.33 m³ / pack | 21.68 kg ~ | 1,475 kg ~ | 4,782.24 m² | 5,179.68 m²
8mm | 10 pcs = 3.60 m² | 68 packs = 244.80 m² | 0.33 m³ / pack | 20.60 kg ~ | 1,400 kg ~ | 4,194 m² | 4,543.20 m²
9.5mm | 8 pcs = 2.88 m² | 68 packs = 195.84 m² | 0.33 m³ / pack | 23.18 kg ~ | 1,576 kg ~ | 2,980.80 m² | 3,231.36 m²
12.5mm | 6 pcs = 2.16 m² | 68 packs = 146.88 m² | 0.33 m³ / pack | 26.30 kg ~ | 1,788 kg ~ | 1,972.08 m² | 2,136.24 m²
Technical details
Type: Gypsum Board
SIZE (MM): 600×600, 300×300, 300×600, 600×1200
THICKNESS: 7mm, 8mm, 9.5mm, 12.5mm
PLASTERBOARD: White
FRONT SURFACE: Bio Proof PVC (antibacterial)
REAR SURFACE: Aluminum foil coating
CARRIER SYSTEM: T-24 white main and cross carriers, duct carrier option
SYSTEM: Seated installation for suspended ceilings
Panel details
Panhygienic Antibacterial Gypsum Panel: antibacterial Bio Proof PVC front coating, aluminum foil rear coating for enhanced moisture resistance; compatible with T-24 main and cross carriers. Installation with double hanger spring, steel dowel and hanger wire for suspended ceiling systems.
Specifications
PANHYGIENIC Hygienic Board is a gypsum ceiling panel with an antibacterial Bio Proof PVC front coating and an aluminum foil rear coating. Designed for suspended plaster ceilings, the combination improves hygiene, cleaning ease and moisture resistance for controlled environments.
Key benefits
- Antibacterial surface prevents bacterial formation
- Available in multiple standard sizes
- Easy to clean and maintain
- Fast assembly and disassembly for ceiling systems
- Resistant to moisture
- Shock and abrasion resistant surface
- Durable material with long service life
Applications / Usage Areas
- Hospitals and clinics
- Healthcare facilities and intensive care units
- Operating theaters and clean rooms
- Commercial and industrial kitchens
- Laboratories and research facilities
- Wet areas requiring hygiene: pools, showers, food preparation zones
Models & description
Panhygienic Antibacterial Gypsum Panel: front surface coated with Bio Proof PVC for antibacterial performance and simplified cleaning; rear side laminated with aluminum foil to enhance moisture resistance. Panels are compatible with T-24 white main and cross carriers and supplied in several size and thickness options.
Delivery Details (table)
THICKNESS | PACKAGE QUANTITY | QUANTITY OF PALLET | VOLUME | PACKAGE WEIGHT | PALLET WEIGHT | 20 DC (24 Ton) | TIR (26 ton)
7mm | 12 pcs = 4.32 m² | 68 packs = 293.76 m² | 0.33 m³ / pack | 21.68 kg ~ | 1,475 kg ~ | 4,782.24 m² | 5,179.68 m²
8mm | 10 pcs = 3.60 m² | 68 packs = 244.80 m² | 0.33 m³ / pack | 20.60 kg ~ | 1,400 kg ~ | 4,194 m² | 4,543.20 m²
9.5mm | 8 pcs = 2.88 m² | 68 packs = 195.84 m² | 0.33 m³ / pack | 23.18 kg ~ | 1,576 kg ~ | 2,980.80 m² | 3,231.36 m²
12.5mm | 6 pcs = 2.16 m² | 68 packs = 146.88 m² | 0.33 m³ / pack | 26.30 kg ~ | 1,788 kg ~ | 1,972.08 m² | 2,136.24 m²
Technical details
Type: Gypsum Board
SIZE (MM): 600×600, 300×300, 300×600, 600×1200
THICKNESS: 7mm, 8mm, 9.5mm, 12.5mm
PLASTERBOARD: White
FRONT SURFACE: Bio Proof PVC (antibacterial)
REAR SURFACE: Aluminum foil coating
CARRIER SYSTEM: T-24 white main and cross carriers, duct carrier option
SYSTEM: Seated installation for suspended ceilings
Panel details
Panhygienic Antibacterial Gypsum Panel: antibacterial Bio Proof PVC front coating, aluminum foil rear coating for enhanced moisture resistance; compatible with T-24 main and cross carriers. Installation with double hanger spring, steel dowel and hanger wire for suspended ceiling systems.
Specifications
- Product line: PANHYGIENIC Hygienic Board
- Front coating: PVC Bio Proof (antibacterial)
- Rear coating: Aluminum foil (moisture resistant)
- Material: Gypsum (white plasterboard)
- Available sizes (mm): 600×600, 300×300, 300×600, 600×1200
- Typical thicknesses: 7mm, 8mm, 9.5mm, 12.5mm
- Carrier system: T-24 white main and cross carriers
- Installation type: Seated
- Key properties: antibacterial, easy to clean, moisture resistant, shock/abrasion resistant, fast assembly/disassembly, long service life
