Acoustic plasterboard

water-repellentdecorativecustom decorative

Overview Coloured gypsum suspended ceiling panels with a PVC vinyl front surface and aluminum-foil-backed rear are designed for modular suspended ceiling systems in commercial and industrial projects. Panels provide aesthetic finish, moisture resistance and options for acoustic perforation.

Price Price depends on material choice, panel size, perforation pattern, color customization and regional logistics. Order quantity, packaging, accessories (carriers, hangers) and installation service affect final cost. Request a quote with project details to obtain accurate pricing for bulk orders and pallet shipments.

Types & Materials

• Types: Coloured gypsum panels available in standard modular sizes (examples: 600×600, 300×300, 300×600, 600×1200).
• Materials: Mineral fiber (improved acoustics and fire resistance), metal (aluminum/steel for durability) or PVC-faced gypsum (moisture resistance and easy maintenance).

Features

• Multiple perforation patterns for acoustic control.
• Standard and custom size options.
• Easy-to-clean PVC surface.
• Quick installation and removal in T‑24 carrier systems.
• Moisture and abrasion resistant finishes.
• Impact-resistant construction for commercial use.
• Long service life with low maintenance.

Colored Gypsum Board Models Economical and visually adaptable panels: choose standard RAL colors or request custom PVC vinyl surface colors for tailored interiors. Available in perforated and non-perforated variants for acoustic requirements.

Colors (examples)

• BLACK
• RED
• GREY

Delivery Details (per package / per pallet) THICKNESS | PACKAGE QUANTITY | QUANTITY PER PALLET | VOLUME | PACKAGE WEIGHT | PALLET WEIGHT | 20' DC (24 Ton) | 40' TIR (26 Ton)
7 mm | 12 pieces = 4.32 m² | 68 packs = 293.76 m² | 0.33 m³ / pack | 21.68 kg ~ | 1,475 kg ~ | 4,782.24 m² | 5,179.68 m²
8 mm | 10 pieces = 3.60 m² | 68 packs = 244.80 m² | 0.33 m³ / pack | 20.60 kg ~ | 1,400 kg ~ | 4,194.00 m² | 4,543.20 m²
9.5 mm | 8 pieces = 2.88 m² | 68 packs = 195.84 m² | 0.33 m³ / pack | 23.18 kg ~ | 1,576 kg ~ | 2,980.80 m² | 3,231.36 m²
12.5 mm | 6 pieces = 2.16 m² | 68 packs = 146.88 m² | 0.33 m³ / pack | 26.30 kg ~ | 1,788 kg ~ | 1,972.08 m² | 2,136.24 m²

Panel details / Technical drawing notes A) Colored Gypsum Board; B) T‑24 Main Carrier (3600 mm); C) T‑24 Cross Carrier (1200 mm); D) T‑24 Cross Carrier (600 mm); E) Double Hanger Spring; F) Steel Dowel; G) Hanger Wire.

Technical specifications

• Type: Gypsum panel for suspended ceilings
• Sizes (mm): 600×600, 300×300, 300×600, 600×1200
• Thickness: 8 mm, 9.5 mm, 12.5 mm
• Available panel colors: White, Green, Red, Crimson (RAL and custom options)
• Front surface: Colored PVC vinyl coating
• Back surface: Aluminum foil on flat panels
• Perforation (mm): Ø6 (line), Ø10 (line), Ø5–10 (line), Ø6–12 (staggered), 12×12 (grid)
• Acoustic fabric: Imported fiberglass in perforated panels
• Carrier system: T‑24 white or channeled carrier
• System type: Lay‑in (sitting) or suspended (hanging)
