Wall sound-absorbing panel SP series

for ceilingMDFsquare

Product overview
Wood acoustic panels designed for conference rooms, cinemas and theaters combining acoustic performance and decorative finish. These products are offered by Favori Yapı under the Sound Panel Wood brand.

How to make wood acoustic panels
Measure and cut wood boards to build a stable frame. Insert sound‑absorbing core (acoustic foam, rockwool or similar) and fix it to the frame. Cover with acoustically transparent fabric and apply the selected surface finish (natural coated or lacquer). Add hangers or mounting hardware for wall or ceiling installation. Verify acoustic performance after installation and adjust perforation or internal fill if required.

Key features

• Effective sound absorption and insulation
• Decorative wooden surface with lacquer or paint options
• Resistant to moisture and abrasion
• Multiple perforation patterns (sequence, series, staggered)
• Available in several colors and finishes
• Quick assembly and disassembly for maintenance

Models

• SP 101 SWALLOWER
• SP 102 -112 SWALLOWER AND REFLECTOR
• SP 103 -113 SWALLOWER AND REFLECTOR
• SP 104 SWALLOW
• SP 105 SWALLOW
• SP 110 REFLECTIVE
• SP 111 REFLECTIVE
• SP 112 (paired with SP 102)
• SP 113 REFLECTIVE

Usage areas

• Shopping centers
• Airports
• Universities and schools
• Metro stations
• Health complexes and hospitals
• Conference rooms
• Cinema and theater halls
• Cafes and restaurants
• Banks

Technical details
Type: Wood MDF – LAM
Size (mm): 600×600, 600×1200
Thickness: 8mm, 12mm, 18mm
Surface: Natural coated or lacquered
Perforations (mm): Ø4 (sequence lineup), Ø6 (series lineup), Ø8 (staggered lineup), Ø10 (staggered lineup)
Acoustic fabric: Acoustic Fabric Soundtex
Color: Lacquer / paint range of colors in the catalog
Carrier system: T-24, T-15-T
System: Sit and Sag
Sound Absorption Class: NRC values 0.37–0.40 and additional NRC options: 0.63, 0.71, 0.84, 0.90, 0.93, 0.95

Technical specifications

• Material: Wood MDF – LAM
• Available sizes: 600×600 mm and 600×1200 mm
• Available thicknesses: 8 mm, 12 mm, 18 mm
• Surface finish: Natural coated or lacquered
• Perforation options: Ø4, Ø6, Ø8, Ø10 with sequence/series/staggered patterns
• Acoustic fabric: Soundtex
• Color: Lacquer/paint range selectable from catalog
• Carrier systems supported: T-24, T-15-T
• Mounting system behavior: Sit and Sag
• Sound absorption (NRC): range including 0.37–0.40 and higher NRC options up to 0.95
