Ceiling sound-absorbing panel ALERIA

basaltmineral woolsquare

Overview
Mineral wool ceiling panels designed for tiled suspended ceiling systems, combining thermal and acoustic performance with non-combustible behavior and low weight.

Mineral wool board insulation
Made from basalt/diabase and recycled slag fibers, mineral wool boards are produced by melting raw materials, spinning them into fibers and compressing into rigid panels. They deliver reliable thermal insulation, sound absorption and fire resistance, suitable for ceilings, walls and roofs in commercial and institutional buildings.

Features

• Acoustic absorption to improve room acoustics
• Aesthetic surface suitable for exposed ceilings
• Effective sound insulation to reduce transmission
• Lightweight construction with low structural impact
• Suitable for modular and removable ceiling systems
• Natural appearance and textured surface
• Simple installation, assembly and disassembly

Models

• Aleria
• Bajkal
• Cortega
• Oasis
• Fine-Fissured
• Dune Supreme

Technical table
TYPE: Rockwool Panel
SIZE (MM): 600×600, 600×1200
THICKNESS: 12.5 mm, 15 mm
RELATIVE MOISTURE RATE: 30°C 80% and 32°C 90%
SURFACE: Maggot
ACOUSTIC PERFORMANCE: NRC ~0.55; W 0.50; Dnc W32 dB
COLOR: White
CARRIER SYSTEM: T-24 White and Winged
SYSTEM: Sitting and Hanging

Usage areas

• Cafes and restaurants
• Airports
• Health complexes and hospitals
• Shopping and entertainment centers
• Conference rooms
• Cinemas and theaters
• Schools and educational buildings
• Banks and financial institutions
• Metro / subway stations

Technical specifications

• Material: Mineral wool (rockwool) from basalt/diabase and recycled slag fibers
• Panel models: Aleria, Bajkal, Cortega, Oasis, Fine-Fissured, Dune Supreme
• Available sizes: 600×600 mm and 600×1200 mm
• Available thicknesses: 12.5 mm and 15 mm
• Acoustic performance: NRC ≈0.55; additional ratings W 0.50; Dnc W32 dB
• Surface finish: Maggot
• Color: White
• Carrier system: T-24 (White) and Winged
• Installation: Sitting or hanging systems
• Relative moisture tolerance: approx. 30°C at 80% RH and 32°C at 90% RH
• Properties: Non-combustible, thermal and acoustic insulation, strong sound insulation, lightweight, easy assembly/disassembly
