Overview
Favori Yapı provides custom suspended (drop) ceilings for residential, commercial and institutional projects. Solutions combine modular T15/T24 carrier systems, a wide selection of panel materials and integrated lighting options to meet acoustic, thermal and design requirements.

Suspended Ceiling Ideas

• Cove lighting: Bedrooms — Concealed cove lights in a false ceiling provide soft, indirect illumination that highlights architectural lines and creates a calm atmosphere.
• Geometric patterns: Living rooms — Arrange tile shapes and layouts to form modern geometric focal points for contemporary interiors.
• Skylight effect: Home offices — Integrate skylight-style modules with task lighting to enhance perceived daylight and visual comfort.
• Wood panel accents: Dining areas — Use suspended wood panels to introduce warmth and texture, suited to rustic or Scandinavian schemes.
• Pendant integration: Entrances — Coordinate pendant fixtures with ceiling recesses for dramatic entrance statements.
• Mixed materials: Commercial spaces — Combine metal, wood and colored tiles to create multifunctional and visually distinct ceilings.
• LED strips: Entertainment areas — Embed adjustable LED strips for dynamic, color-tunable effects.

Drop Ceiling Tiles
Drop ceiling tiles are panels installed into a suspended grid to create a lowered ceiling below the structural slab. They conceal ductwork and services while improving acoustics and thermal performance.

• Materials and styles: mineral fiber, fiberglass, PVC, metal, gypsum and wood panels; various sizes, finishes and perforation options.
• Installation: tiles lay into a suspended grid (T15/T24); suitable for professional installation or experienced installers.
• Maintenance: panels are low-maintenance, cleanable with a damp cloth or vacuum; individual panels can be replaced if damaged.

Suspended Ceiling Grid — Benefits

• Improved aesthetics: conceals services and provides a uniform finish.
• Easy access: removable panels allow access to lighting, HVAC and wiring above the ceiling.
• Acoustic performance: acoustic panels and perforated gypsum reduce reverberation and noise.
• Thermal insulation: selected panels add thermal resistance when specified.

Installation Steps

• Measure and plan: determine room dimensions and grid layout to calculate main runners and cross tees.
• Install perimeter channels: fit L-shaped perimeter profiles along walls.
• Install main runners: mount primary longitudinal carriers to support the grid.
• Install cross tees: connect main runners to form the module grid.
• Place ceiling tiles: cut panels as required and insert into the grid, ensuring alignment.
• Integrate services: install lighting fixtures, vents and other hardware, then finalize adjustments and inspection.

Suspended Ceiling Models (examples)

• Karopan Ceiling (gypsum panels)
• Acoustic Suspended Ceiling (Sound PANNELS acoustic gypsum)
• Metal Suspended Ceiling
• Suspended Ceiling Carrier Systems (metal ceiling frame)
• Colored Gypsum Panels (COLORPAN)
• Antibacterial / Hygienic Panels (PANHYGIENIC)
• Karopan Ceiling Premium
• ARMSTRONG Mineral Fiber Board
• Techni Cap (technical response covers)
• Honeycomb Ceiling
• Mesh / Expanded Metal Ceiling Systems
• Baffle Ceiling
• Linear Suspended Ceiling
• Vector / Vectorial Suspended Ceiling
• Stretch Ceiling (GERGEFF)
• LED lighting in ceiling (FVR)
• Wooden Acoustic Panels

Carrier System Unit m² Analysis (example table)

• 1; T15/24 main carrier 3600 mm; 0.83 m; 0.83 m; 0.83 m; 0.83 m
• 2; T15/24 secondary carrier 1200 mm; 1.66 m; 3.00 m; 1.66 m; 3.33 m
• 3; T15/24 secondary carrier 600 mm; 0.83 m; 2.50 m; –; –
• 4; L angle bar 3000 mm; 0.70 m; 0.70 m; 0.70 m; 0.70 m
• 5; Double springs; 0.7 pcs.; 0.7 pcs.; 0.7 pcs.; 0.7 pcs.
• 6; Steel dowels; 0.7 pcs.; 0.7 pcs.; 0.7 pcs.; 0.7 pcs.
• 7; Hanger wires; 0.7 pcs.; 0.7 pcs.; 0.7 pcs.; 0.7 pcs.
• 8; Weight (kg/m²); 1.25; 1.76; 0.94; 1.54

Usage Areas

• Residential interiors (living rooms, bedrooms, kitchens, bathrooms)
• Offices and corporate spaces
• Retail, shopping malls and stores
• Cafes, restaurants and entertainment venues
• Health complexes and hospitals (hygienic panels)
• Schools and educational institutions
• Gyms, sports arenas, conference and banquet halls
• Cinema and theater auditoriums

Additional Notes

• Suspended ceilings can be customized with perforation options, color finishes, woodgrain or metallic effects and integrated lighting solutions.
• Modular carrier systems (T15/T24) enable easy disassembly for service access and integration with lighting, HVAC and fire protection systems.

Technical specifications

• Available materials: mineral fiber, fiberglass, PVC, metal, gypsum, wood
• Common pricing units: price per m²
• Properties: moisture resistant options (suitable for bathrooms/kitchens with appropriate panels), impact and abrasion resistance, fire-rated options available
• Acoustics: acoustic gypsum panels with perforations for sound absorption
• Thermal: additional thermal insulation possible when specified
• Installation: grid-based T15/T24 carrier systems, perimeter channels, hangers and removable tiles
• Maintenance: individual panel replacement; surface-cleanable finishes (vinyl/PVC coated panels recommended for kitchens)
• Weight examples: dependent on module and panel type (see carrier unit m² analysis for indicative kg/m² values)
