Galvanised steel suspended ceiling aluminumtilefor office
Add to favorites
Compare this product
Characteristics
- Material
- galvanised steel, aluminum
- Type
- tile
- Room/use
- for office, for swimming pool
- Location
- indoor
- Technical characteristics
- acoustic, moisture-resistant
- Aesthetics
- decorative
- Ecological characteristics
- sustainable
- Options
- linear
- Market
- for hospital, for hotel, for restaurant, for office, for airport, for school, for sports clubs, home
- Color
- black, gray
Description
Overview
Baffle suspended ceiling panels are vertically hung metal profiles available in multiple sizes and patterns. The linear vertical design improves air circulation between the ceiling plenum and the occupied space while concealing electrical and mechanical installations. Metal panels with a wood pattern provide the appearance of timber with longer lifespan and simpler maintenance compared with solid wood. In large-span areas, one-way and floating configurations enhance spatial perception and reduce perceived ceiling height without decreasing volumetric capacity.
Key Benefits
Baffle Hanging Ceiling Panel Features
Models
Two model families are offered: U TWISTED and EXTRUSION. U TWISTED illustrates U-shaped/twisted profiles with dedicated dimensional and carrier system options. EXTRUSION refers to continuous extruded profiles with dedicated carrier systems.
Application / Usage Areas
Technical details (tables from product page)
U TWISTED (table)
Material: Aluminum, Galvanized steel
Dimensions: 18 100 mm lower base 30 to 600 mm
Carrier system: Or L claw carrier
Perforation: Ø2, Ø4, Ø5
Acoustic: Acoustic fabric, fiberglass
Color: Standard RAL 9016 or RAL options
EXTRUSION (table)
Material: Aluminum
Dimensions: Lower base 20 mm, height 100 mm
Carrier system: Z and Main Line carrier system
Color: Standard RAL 9016 or RAL options
caractéristiques / spécifications techniques
Baffle suspended ceiling panels are vertically hung metal profiles available in multiple sizes and patterns. The linear vertical design improves air circulation between the ceiling plenum and the occupied space while concealing electrical and mechanical installations. Metal panels with a wood pattern provide the appearance of timber with longer lifespan and simpler maintenance compared with solid wood. In large-span areas, one-way and floating configurations enhance spatial perception and reduce perceived ceiling height without decreasing volumetric capacity.
Key Benefits
- Enables air circulation between ceiling plenum and interior space
- Conceals electrical and mechanical ceiling installations
- Enhances perception of space in large areas (one-way / floating panels)
- Wood-pattern metal options offer timber appearance with extended durability and easier maintenance
Baffle Hanging Ceiling Panel Features
- Multiple pattern options
- Various size options
- Easy to clean
- Fast assembly and disassembly
- Moisture resistant
- Shock and abrasion resistant
- Durable materials ensuring long service life
Models
Two model families are offered: U TWISTED and EXTRUSION. U TWISTED illustrates U-shaped/twisted profiles with dedicated dimensional and carrier system options. EXTRUSION refers to continuous extruded profiles with dedicated carrier systems.
Application / Usage Areas
- Cafes and restaurants
- Gyms
- Hotels
- Factory buildings
- Residential interiors
- Airports
- Healthcare complexes and hospitals
- Shopping and entertainment centers
- Swimming pools
- Schools
- Offices
- Social facilities
- Metro / subway stations
Technical details (tables from product page)
U TWISTED (table)
Material: Aluminum, Galvanized steel
Dimensions: 18 100 mm lower base 30 to 600 mm
Carrier system: Or L claw carrier
Perforation: Ø2, Ø4, Ø5
Acoustic: Acoustic fabric, fiberglass
Color: Standard RAL 9016 or RAL options
EXTRUSION (table)
Material: Aluminum
Dimensions: Lower base 20 mm, height 100 mm
Carrier system: Z and Main Line carrier system
Color: Standard RAL 9016 or RAL options
caractéristiques / spécifications techniques
- Materials: Aluminum; Galvanized steel (U TWISTED: Aluminum, Galvanized steel; EXTRUSION: Aluminum)
- Dimensions (U TWISTED): 18 100 mm lower base 30 to 600 mm
- Dimensions (EXTRUSION): Lower base 20 mm, height 100 mm
- Carrier systems: Or L claw carrier (U TWISTED); Z and Main Line carrier system (EXTRUSION)
- Perforation options: Ø2, Ø4, Ø5
- Acoustic options: Acoustic fabric, fiberglass
- Color: Standard RAL 9016 or other RAL options available
- Features: easy to clean, fast assembly/disassembly, moisture resistant, shock & abrasion resistant, long life
