Acoustic plasterboard

water-repellentdecorativerectangular

Overview
Gypsum board panels for modular suspended ceiling systems. Front surface is PVC vinyl for easy cleaning; back surface is aluminum foil for improved moisture resistance. Gypsum core provides a smooth seamless finish and fire-resistant performance suitable for interior ceilings in residential, commercial and industrial projects.

Benefits

• Lightweight panels for easier handling and installation
• Smooth, seamless aesthetic finish for ceilings
• Fire-resistant core that releases water vapor to delay fire spread
• Acoustic insulation properties to reduce noise transmission
• Cost-effective, widely available solution
• PVC vinyl front: easy to clean and maintain
• Aluminum foil back: enhanced moisture resistance
• Can be cut and shaped for varied ceiling designs; suitable for painting or texturing

Features

• Available in multiple patterns
• Various panel size options
• Easy to clean surface
• Fast assembly and disassembly in modular systems
• Moisture resistance enhanced by back aluminum foil
• Shock and abrasion resistance
• Durable long-life material
• Multiple thickness options

Models

• 975 BEYAZ
• 238 KÜRE BEYAZ
• 154 BEYAZ
• 246 BEYAZ
• G993 KOBRA BEYAZ
• G993 KOBRA SİLVER
• G993-2 KOBRA SARI
• 127-2 ELİT
• 002-LABİRENT
• 631-1-KIRÇILLI
• GRİ MATRİX
• Siyah MATRİX
• G996 PRESTİGE BEYAZ
• G996 PRESTİGE KOYU SILVER
• G996-1 PRESTIGE GOLD
• G996-3 PRESTIGE AÇIK SILVER
• 238-5 KÜRE GRİ
• G238-1 KÜRE GOLD
• KÜRE SARI
• G239-1 PALACA SILVER
• AT10 YAPRAK BEYAZ
• AT10-3 YAPRAK SILVER
• AT01 YAPRAK GOLD
• G239-1 PALACA GOLD
• WE011-2 LINE GRI
• LS-8190-4C LINE GOLD
• WE002-5 AKÇA AĞAÇ
• M14 KAYIN
• MEŞE
• M1 AHŞAP
• WE002-8 LADİN
• TİRE
• WE005-1 ASOS-1
• WE005-2 ASOS-2
• ASOS 3
• LS-E11C ASOS-4
• LS-E43C / LS-E46C ASOS series
• G254-1 İPEK-GOLD

Delivery Details (per package / pallet / truck)
THICKNESS | PACKAGE QUANTITY | QUANTITY OF PALLET | VOLUME | PACKAGE WEIGHT | PALLET WEIGHT | TIR 20 DC (24 Ton) | Truck (26 ton)
7mm | 12 piece = 4,32 m² | 68 package = 293,76 m² | 0,33 m³ / package | 21,68 kg ~ | 1.475 kg ~ | 4.782,24 m² | 5.179,68 m²
8mm | 10 piece = 3,60 m² | 68 package = 244,80 m² | 0,33 m³ / package | 20,60 kg ~ | 1.400 kg ~ | 4.194 m² | 4.543,20 m²
9,5mm | 8 piece = 2,88 m² | 68 package = 195,84 m² | 0,33 m³ / package | 23,18 kg ~ | 1.576 kg ~ | 2.980,80 m² | 3.231,36 m²
12,5mm | 6 piece = 2,16 m² | 68 package = 146,88 m² | 0,33 m³ / package | 26,30 kg ~ | 1.788 kg ~ | 1.972,08 m² | 2.136,24 m²

KAROPAN GYPSUM BOARD FEATURES (additional notes)

• Front surface: PVC vinyl coating for hygiene and cleanability
• Back surface: Aluminum foil coating to increase moisture resistance
• Available sizes: 595×595, 295×295, 295×595, 595×1195 (mm)
• Thickness options: 7 mm, 8 mm, 9.5 mm, 12.5 mm
• Plasterboard colors: White, Green, Red, Burgundy
• Edge type: tapeless
• Carrier system: T-24 (white, colored and channeled carriers)
• System installation type: seated
• Fire class: A1

Technical Specifications

• Product Brand: Karopan
• Panel Type: Gypsum Panel
• Available Sizes (mm): 595×595, 295×295, 295×595, 595×1195
• Thickness: 7 mm; 8 mm; 9.5 mm; 12.5 mm
• Plasterboard Colors: White, Green, Red, Burgundy
• Front Surface: PVC vinyl coating
• Back Surface: Aluminum foil coating
• Edge Surface: tapeless
• Carrier System: T-24 (main and subordinate carriers)
• System: seated
• Fire Class: A1
• Packaging / pallet and truck capacities as per Delivery Details above
