Aluminum acoustic baffle G-BAFFLE

galvanised steelceiling

Introduction
The Baffle slat BAFFLES is an ideal solution for environments requiring high acoustic performance while maintaining a refined aesthetic. Its modern design improves spatial comfort and harmony. The multi-module configuration suits dynamic, contemporary contexts and allows extensive compositional freedom. The result is a visually impactful, elegant and functional ceiling that enhances any space.

Design and variants

• Available versions: G-BAFFLE, Q-BAFFLE (different aesthetics and configurations).
• Modern design intended for acoustic comfort and visual impact.

Finishes and materials
Standard colours: Silver • White • AISI pre-painted. Finish: Smooth • Perforated. Standard materials: Aluminium (3000H46 / 1050AH) and Galvanized steel (DX51DZ). Various manufacturing options and technical drawings are available for installation and composition.

Downloadable documentation
BAFFLES catalogue and BAFFLES workbook available in the download area (technical datasheets and catalogs specific to the product family).

Technical characteristics (table)
European standard: CE - EN 13964
Durability: Class B
Fire resistance: A1
Acoustic absorption: EN ISO 354
Standard colour: Silver • White • AISI pre-painted
Finish: Smooth • Perforated
Standard material: Aluminium (3000H46 / 1050AH) • Galvanized steel (DX51DZ)
Standard thickness: Aluminium 0.5 - 0.6 - 0.8 mm • Steel 0.4 - 0.5 - 0.6 mm

Features / technical specifications

• European standard: CE - EN 13964
• Durability: Class B
• Fire resistance: A1
• Acoustic absorption: EN ISO 354
• Standard colour: Silver, White, AISI pre-painted
• Finish: Smooth, Perforated
• Standard materials: Aluminium (3000H46 / 1050AH) and Galvanized steel (DX51DZ)
• Standard thicknesses: Aluminium 0.5 / 0.6 / 0.8 mm; Steel 0.4 / 0.5 / 0.6 mm
