Crawler excavator EC550E

swivelergonomicfor construction

The EC550E provides the levels of durability and performance more commonly expected from a 60-tonne machine, making it the perfect choice for heavy-duty digging, mass excavation and large site preparation. Boasting superb operator comfort, outstanding levels of uptime, new generation electro-hydraulics, a 20% increase in productivity and 25% improvement in fuel efficiency – this machine raises the bar for what a 50-tonne machine can achieve. Operating weight - 120,000 - 124,100 lbs Gross power - 456 hp Engine speed at max engine torque - 1,300 rpm Bucket capacity - 3.14 - 6 yd³ Lifting capacity, along undercarriage - 35,957 lbs ...at reach / height - 20 / 5 ft Max. digging reach - 40′ 0″ ft in Max. digging depth - 25′ 3″ ft in Breakout force, SAE J1179 (Normal) - 56,450 lbf Breakout force, SAE J1179 (Boost) - 60,500 lbf Tear out force, SAE J1179 (Normal) - 49,480 lbf Overall width (extended) - 13′ 9″ ft in Overall width feet inches retracted - 12′ 2″ ft in Tear out force, SAE J1179 (Boost) - 52,850 lbf Tail swing radius - 12′ 9″ ft in
