The EC250E Hybrid crawler excavator utilizes pioneering Volvo hydraulic hybrid technology to improve fuel efficiency by up to 17%. Using the boom down motion to charge the accumulator, the excavator uses this stored energy to drive the assist motor which powers the engine system. Save big on fuel while benefitting from the power and performance of a conventional EC250E.
Operating weight - 60,032 - 62,413 lbs
Gross power - 225 hp
Engine speed at max engine torque - 1,600 rpm
Bucket capacity - 1 - 2 yd³
Lifting capacity, along undercarriage - 22,156 lbs
...at reach / height - 20 / 5 ft
Max. digging reach - 33′ 11″ ft in
Max. digging depth - 23′ 2″ ft in
Breakout force, SAE J1179 (Normal) - 32,597.3 lbf
Breakout force, SAE J1179 (Boost) - 35,294.9 lbf
Tear out force, SAE J1179 (Normal) - 25,628.2 lbf
Overall width feet inches - 10′ 6″ ft in
Tear out force, SAE J1179 (Boost) - 27,876.3 lbf
Tail swing radius - 10′ 1″ ft in
