Thermal insulation ISOPLATE

XPSpanelrigid panel

Description
Lightweight, versatile insulation panel specially designed for low-profile electric and hydronic underfloor heating systems. Enhances the insulating properties of the sublayer, improves system reaction times and contributes to lower energy consumption.

References (table)
Art.no. | EAN code | Description | Dimensions | U/M
630112 | 8717185493177 | MAGNUM insulation board 3 m² | 5 of 60 x 100 x 1 cm | Set/1
630113 | 8717185494242 | MAGNUM insulation board 4.8 m² | 8 of 60 x 100 x 0.6 cm | Set/1
630120 | 8718532000239 | MAGNUM insulation board 0.72 m² | 60 x 120 x 0.6 cm | pcs/1
630121 | 8718532000246 | MAGNUM insulation board 0.72 m² | 60 x 120 x 1 cm | pcs/1
630122 | 8719743902084 | MAGNUM insulation board 0.72 m² | 60 x 120 x 2 cm | pcs/1
630123 | 8719743902091 | MAGNUM insulation board 0.72 m² | 60 x 120 x 3 cm | pcs/1
630124 | 8719743902107 | MAGNUM insulation board 0.72 m² | 60 x 120 x 4 cm | pcs/1
630125 | 8719743903029 | MAGNUM insulation board 0.72 m² | 60 x 120 x 5 cm | pcs/1

Features

• Flexural modulus according to EN 826 – 10,000–17,000 kPa
• Compressive strength at 10% deformation according to EN 826 – 300 kPa
• Tensile strength according to EN 1607 – 300 kPa
• Water vapour diffusion resistance according to EN 12086 – 80–250 kPa
• Linear thermal expansion coefficient – 0.07 mm/mK
• Application temperature range – -50°C to +70°C
• Reaction to fire class according to EN 13501-1 – E
• Effective thermal resistance indicated: 0.20690 m²K/W

Technical details

• Thickness: From 6 mm to 50 mm
• Extremely lightweight and stable
• Very easy to handle
• Easy to cut in any direction with a cutter
• Resistant to water and mould
• Thermal insulating material
• Extruded polystyrene foam (XPS)
• Both faces covered and reinforced with fiberglass and coated with high-tech polymer mortar
• Especially recommended for heating mats, heating cable and the SlimFit system

Warranty
2 years.

Technical specifications

• Material: extruded rigid polystyrene foam, coated and reinforced with fiberglass and polymeric mortar
• Thickness range: 6 mm – 50 mm (commercial variants available: 0.6 / 1 / 2 / 3 / 4 / 5 cm according to references)
• Flexural modulus (EN 826): 10,000–17,000 kPa
• Compressive strength 10% (EN 826): 300 kPa
• Tensile strength (EN 1607): 300 kPa
• Water vapour diffusion resistance (EN 12086): 80–250 kPa
• Linear thermal expansion coefficient: 0.07 mm/mK
• Operating temperature: -50°C to +70°C
• Reaction to fire class (EN 13501-1): E
• Indicated effective thermal resistance: 0.20690 m²K/W
• Supply forms: boards in different formats and sets according to reference (see references table)
