Strip cladding JI ETÉSIEN 26

metalverticalribbed

Product overview
The JI Étésien 26 NatureBlack is a metal façade profile with beveled ribs designed to reproduce featheredge (overlapped board) cladding. The NatureBlack finish alternates realistic wood-effect waves with deep black ribs to deliver a natural timber appearance while retaining the advantages of metal for ease of installation and reduced maintenance.

Design & appearance

• Beveled ribs that mimic traditional featheredge cladding.
• NatureBlack pre-painted finish combining wood-effect texture and deep black ribs.
• Selectable vertical or horizontal installation to suit architectural intent.

Installation & mounting

• Fixed with visible fasteners onto a secondary frame adapted to the substrate (supporting structure or masonry).
• Requires a level surface or an adjustable subframe.
• Profiles are installed using an overlapping principle (featheredge system).
• A ventilation gap between insulation and the profile is recommended for façade performance.

Dimensions
Length: Min. 1200.0 mm / Max. 6000.0 mm
Width: Max. 871.0 mm

Thickness & weight
0.75 mm: 7.98 kg/m²

Materials & finish

• Standard material: Steel S320 GD.
• Other materials available on request: stainless steel (inox), aluminium.
• Coating example: JI Nature Black (45 µ) — pre-painted steel with wood-effect appearance and high weather resistance.

Reference standards

• Galvanized steel: EN 10346:2015 — tolerances according to EN 10143:2006.
• Coil coating: EN 10169:2022.
• Geometry tolerances: EN 508-1:2021.
• Structural calculations: EN 1993-1-3:2006.

Notes & recommendations

• Metal façade profile reproducing the aesthetic of traditional wood cladding with simplified maintenance.
• Suitable for visible-fastener installation on a correctly designed secondary frame.
• Verify substrate flatness and provide ventilation gap as specified.

Technical specifications

• Model: JI Étésien 26 (NatureBlack finish available).
• Finish: NatureBlack (wood-effect / black ribs).
• Material (standard): Steel S320 GD — other materials on request: inox, aluminium.
• Length range: 1200 mm – 6000 mm.
• Maximum width: 871 mm.
• Example thickness: 0.75 mm (7.98 kg/m²).
• Coating example: JI Nature Black (45 µ) — pre-painted steel, high weather resistance.
• Applicable standards: EN 10346:2015; EN 10169:2022; EN 508-1:2021; EN 1993-1-3:2006.
