Mechanical lock 1037/5
with handlefor sliding doorsmultipoint

Mechanical lock - 1037/5 - Trivel - with handle / for sliding doors / multipoint

Mechanical lock - 1037/5 - Trivel - with handle / for sliding doors / multipoint

Mechanical lock - 1037/5 - Trivel - with handle / for sliding doors / multipoint - image - 2

Mechanical lock - 1037/5 - Trivel - with handle / for sliding doors / multipoint - image - 3

Add to favorites

Compare this product

Go to the Trivel website for more information

Characteristics

Mechanism: mechanical
Opening system: with handle
Product applications: for sliding doors
Number of locking points: multipoint
Market: commercial
Installation: surface-mounted
Material: stainless steel
Color: silver-colored
Other characteristics: high-security

Description

HOOK – Sliding door locks
Overview
Lock for sliding doors with a key‑operated retractable hook, designed for glass applications. Clamping plates for glass, stainless steel fronts and decorative covers, and A2 stainless steel fasteners. Euro‑profile multipoint security cylinder with 40 mm cylinder entry. Certified to UNE‑EN standards for mechanical resistance and corrosion resistance.

Available variants

1037 — Retractable hook, cylinder
1037/1 — Retractable hook, cylinder, fixed knobs 002R
1037/2 — Retractable hook, half cylinder, fixed knob 002R
1037/3 — Retractable hook, cylinder, fixed knobs 015R
1037/4 — Retractable hook, half cylinder, fixed knob 015R
1037/5 — Retractable hook, thumbturn, fixed knobs 002R
1037/6 — Retractable hook, thumbturn, half fixed knob 015R
1037/7 — Retractable hook, thumbturn, fixed knobs 015R
1037/8 — Retractable hook, thumbturn, half fixed knob 015R
1037/9 — Retractable hook, thumbturn

Documentation available
Instructions for fixed knobs (PDF).

Technical characteristics / specifications

Glass clamping plates manufactured in injection‑moulded aluminium alloy with epoxy paint coating
Fasteners in stainless steel A2
Front plates in stainless steel AISI 304
Decorative covers in stainless steel AISI 316
Handles and knobs in stainless steel AISI 316
Glass clamping gaskets made of PE material
Key‑operated retractable hook
Euro‑profile multipoint security cylinder
Cylinder entry: 40 mm
If fixed actuators are required for pull‑type use, these will be knobs only
Certified to UNE‑EN 1935:2002/AC:2004, Grade 7 / 200,000 cycles
Certified to UNE‑EN 1670:2007/AC:2008, Grade 5 (highest corrosion resistance)
Standard finishes: bright stainless and satin stainless; recommended glass thickness: 10 mm
Options on request: electrolytic finishes and RAL colours
