Mechanical lock 1037/6

with handlefor sliding doorsmultipoint

Description
Hardware designed for sliding doors featuring a retractable hook operated by key and an euro‑profile multipoint cylinder. Intended for door systems in enclosure and glazing projects where stainless materials and corrosion resistance are required.

Available variants

• 1037 — Retractable hook, cylinder
• 1037/1 — Retractable hook, cylinder with fixed knobs 002R
• 1037/2 — Retractable hook, cylinder with ½ knob 002R fixed
• 1037/3 — Retractable hook, cylinder with fixed knobs 015R
• 1037/4 — Retractable hook, cylinder with ½ knob 015R fixed
• 1037/5 — Retractable hook, locking mechanism with fixed knobs 002R
• 1037/6 — Retractable hook, locking mechanism with ½ knob 015R fixed
• 1037/7 — Retractable hook, locking mechanism with fixed knobs 015R
• 1037/8 — Retractable hook, locking mechanism with ½ knob 015R fixed
• 1037/9 — Retractable hook, locking mechanism

General features

• Glass clamping plates in aluminum alloy produced by injection molding and coated with epoxy paint
• Fasteners in stainless steel A2
• Front plates in stainless steel AISI 304
• Cover plates in stainless steel AISI 316
• Handles and knobs in stainless steel AISI 316
• Glass sealing gaskets in PE material
• Retractable hook operated by key
• Euro‑profile security multipoint cylinder
• Cylinder entry: 40 mm
• If fixed actuators for pull-handle use are required, only knobs are permitted
• Certified to UNE-EN 1935:2002/AC:2004, Grade 7 / 200,000 cycles
• Certified to UNE-EN 1670:2007/AC:2008, Grade 5 (maximum corrosion resistance)

Standard manufacturing

• Finishes: Polished stainless steel – Satin stainless steel
• Recommended glass thickness: 10 mm

Options on request

• Electrolytic finishes
• RAL colours

Characteristics / Technical specifications

• Main materials: aluminum alloy (clamping plates), stainless steel A2 (fasteners), AISI 304 (front plates), AISI 316 (covers, handles and knobs)
• Gaskets: PE material
• Type of locking: retractable hook operated by key
• Cylinder: euro‑profile security multipoint, cylinder entry 40 mm
• Glass thickness: 10 mm
• Certifications: UNE-EN 1935:2002/AC:2004 (Grade 7 / 200,000 cycles); UNE-EN 1670:2007/AC:2008 (Grade 5 corrosion resistance)
• Fixed actuators: only knobs if pull‑handle use is required
• Standard finishes: polished and satin stainless steel; additional options on request (electrolytic, RAL)
