Mechanical lock 1037/7
with handlefor sliding doorsmultipoint

Mechanical lock - 1037/7 - Trivel - with handle / for sliding doors / multipoint

Mechanical lock - 1037/7 - Trivel - with handle / for sliding doors / multipoint - image - 2

Mechanical lock - 1037/7 - Trivel - with handle / for sliding doors / multipoint - image - 3

Add to favorites

Compare this product

Go to the Trivel website for more information

Characteristics

Mechanism: mechanical
Opening system: with handle
Product applications: for sliding doors
Number of locking points: multipoint
Market: commercial
Installation: surface-mounted
Material: stainless steel
Color: silver-colored
Other characteristics: high-security

Description

Description
HOOK – Sliding door locks. Lock system for sliding doors with retractable hook and multiple cylinder and knob configurations. Variants available:

1037 – Retractable hook, cylinder
1037/1 – Retractable hook, cylinder with fixed 002R knobs
1037/2 – Retractable hook, cylinder with half fixed 002R knob
1037/3 – Retractable hook, cylinder with fixed 015R knobs
1037/4 – Retractable hook, cylinder with half fixed 015R knob
1037/5 – Retractable hook, deadbolt with fixed 002R knobs
1037/6 – Retractable hook, deadbolt with half fixed 015R knob
1037/7 – Retractable hook, deadbolt with fixed 015R knobs
1037/8 – Retractable hook, deadbolt with half fixed 015R knob
1037/9 – Retractable hook, deadbolt

GENERAL FEATURES

Glass clamping plates made of aluminum alloy produced by injection and coated with epoxy paint
Fasteners in stainless steel A2
Faceplates in stainless steel AISI 304
Decorative covers in stainless steel AISI 316
Handles and knobs in stainless steel AISI 316
Glass clamping gaskets made of PE material
Retractable hook operated by key
Euro-profile multipoint security cylinder
Cylinder entry: 40 mm
If fixed actuators are required for pull-handle use, only knobs are available as fixed actuators
Certified to UNE-EN 1935:2002/AC:2004, Grade 7 / 200,000 cycles
Certified to UNE-EN 1670:2007/AC:2008, Grade 5 (highest corrosion resistance)

STANDARD MANUFACTURE

Finishes: polished stainless – satin stainless
Recommended glass thickness: 10 mm

OPTIONS ON REQUEST

Electrolytic finishes
RAL colours

CHARACTERISTICS / TECHNICAL SPECIFICATIONS

Main materials: aluminum alloy (clamping plates), stainless steels A2, AISI 304 and AISI 316
Locking system: retractable hook operated by key
Cylinder: euro-profile multipoint security cylinder, 40 mm entry
Recommended glass thickness: 10 mm
Fasteners: stainless steel A2
Clamping gaskets: PE material
Certifications: UNE-EN 1935:2002/AC:2004 (Grade 7 / 200,000 cycles) and UNE-EN 1670:2007/AC:2008 (Grade 5)
Standard finishes: polished and satin stainless; options on request: electrolytic and RAL colours
