Rectangular roof tile H-SELECTION VIENNA

specialclaysmall

Overview
The perfect flatness turns each piece into a work of art. The frontal furrow gives the roof a uniform appearance. Vienna roof tile is laid using a straight-bond installation method.

Data sheet
Vienna roof tile
A 460 mm
B 255 mm
C 30 mm
Pieces per m2: 11.5
Weight per piece: 3.6 kg
Longitudinal fit: 396 mm (+5 mm; -75 mm)
Transversal fit: 214 mm (±1 mm)
Units per pallet: 216 / 288
Weight per pallet: 778 kg / 1,037 kg
Laying: Straight bond
*Tile dimensions admit a normative tolerance of approximately +/-2%
**Theoretical value: recalculate on site with the tiles to be used

Features

• EXCELLENT FLATNESS: Individual curing on H support ensures flat surfaces with no contact marks.
• HIGH DEFINITION: Manufactured with gypsum moulds for a finer texture and precise definition on each piece.
• LOW ABSORPTION: Reduced water uptake for improved resistance to frost and mould.
• LIFETIME WARRANTY: 100-year warranty reflecting manufacturing quality.

Palette (design and color range)

• TVRK RED
• TVPK SLATE
• TVYK GALAXY
• TVRRK RUSTIC RED
• SPECIAL COLORS ON REQUEST

Certifications and compliance
The Vienna tile complies with standard EN 1304. Certified characteristics include appearance, geometric dimensions, flexural strength, impermeability and frost resistance. Color variations within a batch are permitted; mix tiles from two or more pallets of the same batch on site to ensure homogeneous finishing and avoid mixing tiles from different production dates on the same roof slope.

Technical specifications

• Model: Vienna
• Series: H-Selection
• Dimensions (A × B × C): 460 mm × 255 mm × 30 mm
• Pieces per m2: 11.5
• Weight per piece: 3.6 kg
• Longitudinal fit: 396 mm (+5 mm; -75 mm)
• Transversal fit: 214 mm (±1 mm)
• Units per pallet: 216 / 288
• Weight per pallet: 778 kg / 1,037 kg (depending on pallet)
• Recommended laying: Straight bond
• Absorption: low (klinker) — resistance to frost and mould
• Standard: EN 1304
• Warranty: 100 years (manufacturer stated)
