Interlocking roof tile SELECTUM

claysmallred

Description
Selectum is a traditional-style roof tile in klinker terracotta integrating the FlexiLock installation system for adjustable laps and simplified fitting. Tile count per square metre varies from 11 to 14 depending on longitudinal and transversal lap settings.

Data sheet
Selectum roof tile (H-Selection)
Dimensions (A x B x C) — 468 mm x 280 mm x 75 mm (18.4 x 11 x 3 in)
Pieces / m2 — 11 - 14
Weight per piece — 3,500 g (7.71 lbs)
Longitudinal fit (theoretical) — 348 - 383 mm (13.7 - 15.07 in)
Transversal fit (theoretical) — 206 - 231 mm (8.1 - 9.09 in)
Units per pallet — 240 / 320
Weight per pallet — 840 kg / 1,120 kg (approx.)
Laying system — Straight bond

Key features

• FlexiLock: adjustable pureaux for simplified installation and optimal adaptation to different roof geometries.
• Excellent flatness: individual curing on H supports avoids contact points and ensures regular surface planarity.
• High definition: gypsum moulds produce a fine texture and precise definition on each piece.
• Low absorption (klinker): improved resistance to frost and reduced risk of mould formation.
• 100-year warranty: long-term manufacturing warranty subject to manufacturer conditions.

Color range

• TSPRK PROVENCE
• TSPK SLATE
• TSRRK RUSTIC RED
• TSEC COGNAC
• TSEZ LIGHT BLUE
• TSEA DARK BLUE
• TSEV LIGHT GREEN
• TSEO DARK GREEN
• TSECR RUSTIC COGNAC
• TSEG CARMINE
• TSEN BLACK
• TSRK RED
• TSMK BROWN

Notes on color and batches
Intentional colour variations within a batch produced for aesthetic effect are permissible and affect the whole batch. For single-colour tiles, variations inherent to the ceramic process are accepted. It is recommended not to mix tiles from different production batches on the same roof plane and, when possible, to use tiles from two or more pallets of the same batch for a uniform finish.

Technical specifications

• Model / Range: Selectum (H-Selection)
• Dimensions A x B x C: 468 mm x 280 mm x 75 mm
• Pieces per m²: 11 - 14
• Weight per piece: 3,500 g
• Longitudinal fit (theoretical): 348 - 383 mm
• Transversal fit (theoretical): 206 - 231 mm
• Units per pallet: 240 / 320
• Weight per pallet: 840 kg / 1,120 kg (approx.)
• Laying system: Straight bond
• Installation system: FlexiLock
• Material: Klinker terracotta (low absorption)
• Tolerances: dimensions allow approx. +/-2%; some values are theoretical and must be recalculated on site
