Flat roof tile H-SELECTION VISUM3

ceramicsmallred

Product overview
Visum3 is a single-piece roof tile designed to reproduce the visual effect of three tiles in one element. Its geometry and finishes enable a distinct three-effect aesthetic while allowing installation with a broken bond (CROSS BOND) pattern.

Data sheet
Visum3 roof tile
A: 471 mm / 11"
B: 280 mm / 18.54"
C: 35 mm / 1.38"
Pieces per m2: 11.5 (106.7 per sq.)
Weight per piece: 3.55 kg / 7.83 lbs
Longitudinal fit: 187 mm (+4 mm / -10 mm) / 7.36" (+0.16 / -0.39)
Transversal fit: 435 mm (±1 mm) / 17.12" (±0.04)
Units per pallet: 216 / 288
Weight per pallet: 767 kg / 1,691 lbs (216 units) / 1,022 kg / 2,253 lbs (288 units)
Installation: Broken bond (CROSS BOND)

Key features

• HIGH DEFINITION ON EACH PIECE: Individual curing of each tile using an H support for excellent flatness without contact marks.
• EXCELLENT FLATNESS: Manufactured with gypsum moulds to achieve a finer texture and precise definition.
• LOW ABSORPTION: Reduced water uptake improves resistance to frost and limits mould formation.
• WARRANTY: 100-year warranty covering manufacturing quality and durability.

Color range

• TWPK SLATE
• TWGIK GRIS IDELLA
• TWRRK RUSTIC RED
• TWRUK RUSSET

Additional notes
Color variations within a single supply batch are intentional and accepted as part of the ceramic finishing process. Slight tone differences can occur between pallets. For a uniform finish, mix two or more pallets from the same production batch on site. Avoid mixing tiles from different manufacturing dates on the same roof plane.

Technical specifications

• Model: Visum3
• Commercial range: H-Selection
• Dimensions (A x B x C): 471 mm x 280 mm x 35 mm (11" x 18.54" x 1.38")
• Pieces per m2: 11.5 (106.7 per sq.)
• Weight per piece: 3.55 kg (7.83 lbs)
• Longitudinal fit: 187 mm (+4 / -10 mm)
• Transversal fit: 435 mm (±1 mm)
• Units per pallet: 216 / 288
• Weight per pallet: 767 kg / 1,022 kg
• Installation method: Broken bond (CROSS BOND)
• Manufacturing: Individual curing with H support; gypsum moulds for fine texture
• Performance: Low water absorption for increased frost and mould resistance
