Curved roof tile H-SELECTION SELECTUM

interlockingMarseillesclay

Overview
Selectum is a traditional klinker-quality roof tile designed for architectural applications. It features the FlexiLock installation system for simplified laying and an adjustable fit. Coverage may vary between 11 and 14 pieces per m² depending on laying configuration.

Key features

• EXCELLENT FLATNESS: Individual curing on H-support ensures excellent flatness with no contact marks.
• HIGH DEFINITION TEXTURE: Gypsum mould manufacturing delivers a refined surface texture and clear definition on each piece.
• LOW WATER ABSORPTION (KLINKER): Improved resistance to frost and mould formation.
• LONG WARRANTY: Manufacturer warranty up to 100 years, reflecting durable manufacturing quality.

Technical data
Selectum roof tile
Dimensions*: A 468 mm / 18.4"
B 280 mm / 11"
C 75 mm / 3"
Pieces / m2: 11 - 14
Weight per piece: 3,500 g / 7.71 lbs
Longitudinal fit**: 348 - 383 mm / 13.7 - 15.07"
Transversal fit**: 206 - 231 mm / 8.1 - 9.09"
Units per pallet: 240 / 320
Weight per pallet: 840 kg / 1,120 kg
Laying: Straight bond
*Tile dimensions allow a tolerance of approximately +/-2%
**Theoretical values: recompute on site with the tiles to be used

Color range

• TSPRK PROVENCE
• TSPK SLATE
• TSRRK RUSTIC RED
• TSEC COGNAC
• TSEZ LIGHT BLUE
• TSEA DARK BLUE
• TSEV LIGHT GREEN
• TSEO DARK GREEN
• TSECR RUSTIC COGNAC
• TSEG CARMINE
• TSEN BLACK
• TSRK RED
• TSMK BROWN

Installation system
The FlexiLock system provides variable longitudinal and transversal fits, facilitating fast adjustment on site. Coverage ranges from 11 pieces/m² (long fit 383 mm / trans. 231 mm) to 14 pieces/m² (long fit 348 mm / trans. 206 mm).

Notes & compliance
Color variations within a production batch are permissible for aesthetic reasons. For single-colour tiles, slight shade differences due to the ceramic process are accepted. Avoid mixing tiles from different batches on the same roof plane. Selectum complies with EN 1304; certified properties include appearance, geometric characteristics, flexural strength, impermeability and frost resistance.
