Solar control glass panel 4BIRD® FRIT

insulatingthermal insulatingsolar

Description
4BIRD® FRIT combines a screen-printed patterned pane with a coated thermal insulating glass, with or without solar protection. This combination creates a visible contrast that helps birds perceive the façade glazing and reduces collision risk. 4BIRD® FRIT supports building energy-performance objectives while protecting biodiversity.

• Energy savings: significant reduction in lighting and cooling demand thanks to selectivity above 1.7.
• Thermal comfort: reduces solar heat gains and provides thermal insulation (Ug ≤ 1.1).
• Biodiversity protection: solutions that lower the risk of bird collisions.

Applications
The 4BIRD® FRIT range offers solutions for all project types, including new-build and renovation, residential and non-residential. It addresses clients and project owners wishing to protect birds from collision risk and contributes to points for LEED certification (Pilot Credit #55: bird collision deterrence).
The coated glasses selected for the 4BIRD® FRIT range have low visible reflectance (below 15%). Multiple compositions are possible depending on solar protection and thermal insulation requirements.
Standard glazed sizes for the 4BIRD® FRIT range are 4 200 x 2 000 mm. Other sizes: available on request from the manufacturer or processor.

Advantages

• Summer and winter thermal comfort
• Natural daylight transmission
• Durability and biodiversity protection
• Energy savings

Performance
The 4BIRD® FRIT range benefits from the properties and performance of coated glasses such as COOL-LITE® XTREME, SKN and ECLAZ®. The entire range has been evaluated as "bird friendly" by the American Bird Conservancy (ABC). The Threat Factor (TF) used by ABC assesses material effectiveness: a glazing is considered bird-friendly if its TF is ≤ 30. The range meets criteria that enable birds to perceive the glazing and limit collision risk.

Technical characteristics / specifications

• Commercial name: 4BIRD® FRIT
• Brand: Saint-Gobain Glass
• Type: Screen-printed patterned glazing + coated glass (optional solar protection)
• Selectivity: greater than 1.7 (contributes to energy savings for lighting and cooling)
• Thermal insulation: Ug ≤ 1.1 (depending on composition)
• Visible reflectance of selected coated glasses: below 15%
• Associated glass series: COOL-LITE® XTREME, SKN, ECLAZ®
• Bird assessment: evaluated as "bird friendly" by the American Bird Conservancy (TF ≤ 30 to be judged bird-friendly)
• Standard dimensions available: 4 200 x 2 000 mm (other sizes on request)
• Label range: part of the "les engagés" range (environment, health, resources, well-being criteria)
