Large excavator SE210W

rubber-tiredcompactfor rock

Product
Wheeled excavator SE210W designed for medium-class earthmoving, urban and infrastructure operations.

Key features

• Powertrain and hydraulics: 116 kW engine (2000 rpm) combined with imported hydraulic components to minimize pressure loss and optimize fuel consumption.
• Maintenance and operator access: Centralized oil and high-precision fuel filters located near the right-side door; accessible coolant refill and air filter elements for simplified service.
• Versatility and reliability: Reinforced structural components and compatibility with various booms, arms, buckets and attachments to adapt to diverse jobsite conditions.
• Mobility and emissions: Wheeled undercarriage with travel speeds 3.3 / 5.4 km/h; compliant with EU Stage IIIA emissions.

Technical parameters

• Model: SE210W
• Operating weight: 21100 kg
• Engine power: 116 kW @ 2000 rpm
• Bucket capacity: 0.9 m³
• Dimensions (L×W×H): 9543 × 2800 × 3039 mm
• Bucket rod digging force: 99.5 kN
• Bucket digging force: 135 kN
• Rotating speed: 0–11 r/min
• Travel speed: 3.3 / 5.4 km/h
• Max digging height: 10029 mm
• Max digging distance: 9860 mm
• Max digging depth: 6541 mm
• Emissions: EU Stage IIIA

Application cases

• Shantui SE350 excavator used in a railway construction project in Malaysia
• Shantui SE500LCW excavator operating in Kyrgyzstan
• Shantui SE550LC working on a mining site in Cambodia
• Shantui SE370LC excavator deployed on a mining site in Eritrea
• Shantui SE335LC excavator used in alluvial gold ore operations in Uganda
• Shantui SE220LC excavator with breaker working in desert conditions in Saudi Arabia

Specifications

• Model: SE210W
• Category: Medium Excavator
• Operating weight: 21100 kg
• Engine power: 116 kW @ 2000 rpm
• Bucket capacity: 0.9 m³
• External dimensions (L×W×H): 9543 × 2800 × 3039 mm
• Bucket rod digging force: 99.5 kN
• Bucket digging force: 135 kN
• Rotating speed: 0–11 r/min
• Travel speed: 3.3 / 5.4 km/h
• Maximum digging height: 10029 mm
• Maximum digging distance: 9860 mm
• Maximum digging depth: 6541 mm
• Emissions: EU Stage IIIA
