Large excavator SE210W
rubber-tiredcompactfor rock

Large excavator - SE210W - SHANDONG SHANTUI CONSTRUCTION MACHINERY IMP&EXP CO.,LTD - rubber-tired / compact / for rock
Large excavator - SE210W - SHANDONG SHANTUI CONSTRUCTION MACHINERY IMP&EXP CO.,LTD - rubber-tired / compact / for rock
Add to favorites
Compare this product

Characteristics

Product line
large
Locomotion
rubber-tired
Type
compact, for rock
Other characteristics.
diesel, for construction, loading
Operating weight

21,100 kg
(46,517.5 lb)

Engine power

116 kW
(157.7 hp)

Bucket capacity

0.9 m³
(31.783 ft³)

Description

Product
Wheeled excavator SE210W designed for medium-class earthmoving, urban and infrastructure operations.

Key features
  • Powertrain and hydraulics: 116 kW engine (2000 rpm) combined with imported hydraulic components to minimize pressure loss and optimize fuel consumption.
  • Maintenance and operator access: Centralized oil and high-precision fuel filters located near the right-side door; accessible coolant refill and air filter elements for simplified service.
  • Versatility and reliability: Reinforced structural components and compatibility with various booms, arms, buckets and attachments to adapt to diverse jobsite conditions.
  • Mobility and emissions: Wheeled undercarriage with travel speeds 3.3 / 5.4 km/h; compliant with EU Stage IIIA emissions.


Technical parameters
  • Model: SE210W
  • Operating weight: 21100 kg
  • Engine power: 116 kW @ 2000 rpm
  • Bucket capacity: 0.9 m³
  • Dimensions (L×W×H): 9543 × 2800 × 3039 mm
  • Bucket rod digging force: 99.5 kN
  • Bucket digging force: 135 kN
  • Rotating speed: 0–11 r/min
  • Travel speed: 3.3 / 5.4 km/h
  • Max digging height: 10029 mm
  • Max digging distance: 9860 mm
  • Max digging depth: 6541 mm
  • Emissions: EU Stage IIIA


Application cases
  • Shantui SE350 excavator used in a railway construction project in Malaysia
  • Shantui SE500LCW excavator operating in Kyrgyzstan
  • Shantui SE550LC working on a mining site in Cambodia
  • Shantui SE370LC excavator deployed on a mining site in Eritrea
  • Shantui SE335LC excavator used in alluvial gold ore operations in Uganda
  • Shantui SE220LC excavator with breaker working in desert conditions in Saudi Arabia


Specifications
  • Model: SE210W
  • Category: Medium Excavator
  • Operating weight: 21100 kg
  • Engine power: 116 kW @ 2000 rpm
  • Bucket capacity: 0.9 m³
  • External dimensions (L×W×H): 9543 × 2800 × 3039 mm
  • Bucket rod digging force: 99.5 kN
  • Bucket digging force: 135 kN
  • Rotating speed: 0–11 r/min
  • Travel speed: 3.3 / 5.4 km/h
  • Maximum digging height: 10029 mm
  • Maximum digging distance: 9860 mm
  • Maximum digging depth: 6541 mm
  • Emissions: EU Stage IIIA
