Medium excavator SW210

rubber-tiredhandlingdiesel

Product
Wheel excavator SW210 built for medium‑heavy excavation, loading and material handling tasks in construction, mining and rail projects.

Key specifications (summary)

• Operating weight: 21,800 kg
• Engine power: 140 kW @ 2000 rpm (Weichai WP7H)
• Bucket capacity: 0.9 m³

Characteristics

• Convenient maintenance: centrally arranged high-precision air, engine oil and fuel filters for easier inspection and replacement.
• Intelligence and comfort: customised cab with heating/cooling, safety equipment and a 10.1-inch intelligent touch display for real-time machine and working-condition monitoring.
• Travel performance: independent split-type ZF gearbox for optimised power distribution, improved heat dissipation and smooth gear shifting during long runs.
• Structure and durability: strengthened box-type undercarriage design and protected dozer blade cylinder to reduce collision risk and support heavy loads.
• Powertrain: Weichai WP7H engine (140 kW) to meet high-load excavation requirements.

Parameters
Parameter - SW210
Operating weight (kg): 21800
Engine power (kW/rpm): 140/2000
Bucket capacity (m³): 0.9
External dimensions (mm): 9630 × 2510 × 3425
Arm digging force (kN): 107
Bucket digging force (kN): 147
Rotating speed (r/min): 11 r/min
Travel speed (km/h): 10 / 37
Maximum digging height (mm): 10262
Maximum digging distance (mm): 9860
Maximum digging depth (mm): 6283
Emissions: Tier 3


Application cases (examples)

• Deployed in railway maintenance, open-pit mining and urban construction sites; case images typically show SW-series excavators in loading and trackside operations.

Technical specifications

• Operating weight: 21800 kg
• Engine power: 140 kW @ 2000 rpm
• Bucket capacity: 0.9 m³
• External dimensions: 9630 × 2510 × 3425 mm
• Arm digging force: 107 kN
• Bucket digging force: 147 kN
• Rotating speed: 11 r/min
• Travel speed: 10 / 37 km/h
• Maximum digging height: 10262 mm
• Maximum digging distance: 9860 mm
• Maximum digging depth: 6283 mm
• Emissions: Tier 3
