Modern ceiling light CITY GLOBE CATENARY

sphericalpolycarbonateglass

Finish
Painted aluminum and metal. Outer shade in grey-toned polycarbonate. Inner shade in crackled glass.

LED info

• System power: 23W
• Luminaire luminous flux: 1900 lm
• CCT: 3000K
• SDCM: 3
• CRI: >80
• L80: 80,000 h

Installation
Catenary fitting 3–6 mm. Wire excluded.

Connection
Terminal block 5 x 4 mm2 inside housing.

Classification
IP20.

Design
Thomas Bernstrand, 2019.

Standard colours
Other colours on request.

Standard glass shades
Available in cognac, grey, red and other finishes.

Product specification
POWER | KELVIN | CRI | INTERNAL SHADE | TYPE | ART.
LED | | | | |
23W/1900LM | 3000K | >80 | Grey | On/Off | 12066306-30
23W/1900LM | 3000K | >80 | Grey | Dali | 12066306D30
23W/1900LM | 3000K | >80 | Cognac | On/Off | 12067306-30
23W/1900LM | 3000K | >80 | Cognac | Dali | 12067306D30
23W/1900LM | 3000K | >80 | Red | On/Off | 12068306-30
23W/1900LM | 3000K | >80 | Red | Dali | 12068306D30
D = Dimmable DALI or SwitchDim. | | | | |
E27 Excl. light source | | | | |
E27/Max 20W | | | Grey | | 12075306
E27/Max 20W | | | Cognac | | 12076306
E27/Max 20W | | | Red | | 12077306

Technical specifications

• Materials: Painted aluminum and metal; outer shade in grey-toned polycarbonate; inner shade in crackled glass.
• Light source options: Integrated LED 23W (1900 lm) or E27 (max 20W, lamp excluded).
• Colour temperature: 3000K.
• CRI: >80.
• Luminaire lifetime: L80 80,000 h.
• Dimming: DALI or SwitchDim for dimmable versions.
• Protection class: IP20.
• Connection: Terminal block 5 x 4 mm2 inside housing.
• Installation: Catenary fitting 3–6 mm (wire excluded).
• Designer: Thomas Bernstrand (2019).
• Available internal shade colours: Grey, Cognac, Red (others on request).
• Key article numbers for LED On/Off: 12066306-30 (Grey), 12067306-30 (Cognac), 12068306-30 (Red).
• Key article numbers for LED DALI: 12066306D30 (Grey), 12067306D30 (Cognac), 12068306D30 (Red).
• Key article numbers for E27 variants: 12075306 (Grey), 12076306 (Cognac), 12077306 (Red).
