Pendant lamp SLIZES

painted metalfabricpolyester

Finish
Painted metal in black. Sound absorbing slices made of polyester and bi-component fibre. Fabric Hush/Gabriel. Can be ordered with 2-, 3-, or 4-layer slices. Minimum 2 slices (positions A + B delivered as standard). The slices are two-coloured, one colour on each side.

LED info
System power 11W. Luminaire luminous flux 884 LM. CCT 3000K. SDCM 3. CRI >90. L90 60,000 h. GU10-socket available as an option.

Installation
Suspended via cable.

Connection
2 m cable with DCL plug or terminal block 3x4 mm2. DALI version: 5x4 mm2.

Classification
IP20.

Design
Halskov & Dalsgaard, 2022.

Standard colours slice B

• Other colours on request.

Standard colours slice A, C & D

• Other colours on request.

Product specification
POWER | LUMINAIRE FLUX | MODEL | KELVIN | CRI | COLOUR | ART.
11W | 884LM | On/Off | 3000K | >90 | Black | 12120106-30
11W | 884LM | DALI | 3000K | >90 | Black | 12120106D30
Including dimmable GU10 light source
4.9W/6.2W | 355LM/515LM | | 2700K/3000K | >90 | Black | 12121106
Light source GU10
4.9W/GU10 | 355LM | | 2700K | >90 | | L70073
6.2W/GU10 | 515LM | | 3000K | >90 | | L70074

Sound‑absorbing slices - POSITION
POSITION | Diameter | Colour combinations | ART.
Position A: Diameter 375 mm | A | 60155 Light grey / 60900 Dark grey combinations | S60155-A, S60900-A, S64148-A, S62068-A, S68160-A, S61174-A, S63058-A, S61176-A, S61226-A, S61225-A, S67046-A, S66169-A
Position B: Diameter 580 mm or 800 mm | B | 60155 Light grey / 60900 Dark grey combinations | S60155-B1, S60900-B1, S60155-B3, S60900-B3
Position C: Diameter 285 mm | C | 60155 Light grey / 60900 Dark grey combinations and other pairings | S60155-C, S60900-C, S64148-C, S62068-C, S68160-C, S61174-C, S63058-C, S61176-C, S61226-C, S61225-C, S67046-C, S66169-C
Position D: Diameter 170 mm | D | 60155 Light grey / 60900 Dark grey combinations and other pairings | S60155-D, S60900-D, S64148-D, S62068-D, S68160-D, S61174-D, S63058-D, S61176-D, S61226-D, S61225-D, S67046-D, S66169-D

Technical specifications

• Product name: Slizes
• Brand: Zero
• Designer: Halskov & Dalsgaard, 2022
• Material: Painted metal (black); sound-absorbing slices of polyester and bi-component fibre; fabric Hush/Gabriel
• Construction: Two-coloured slices, one colour on each side; minimum 2 slices (positions A+B standard); available in 2, 3 or 4 layers
• Light source options: Integrated LED (11W system) or GU10 light source options (4.9W / 6.2W)
• System power (integrated LED): 11W
• Luminaire flux (integrated LED): 884 LM
• GU10 variants flux: 355 LM (4.9W) / 515 LM (6.2W)
• Correlated Colour Temperature: 2700K / 3000K (typical 3000K)
• CRI: >90
• SDCM: 3
• Lifetime: L90 60,000 h
• IP rating: IP20
• Mounting: Suspended via cable
• Connection: 2 m cable with DCL plug or terminal block 3x4 mm2; DALI: 5x4 mm2
• Available sizes and positions: A (Ø 375 mm), B (Ø 580 / 800 mm), C (Ø 285 mm), D (Ø 170 mm)
• Article numbers: multiple ART. numbers per size/colour (see product table)
• Options: DALI variant, GU10 socket option
• Documentation: product sheet, acoustic facts, installation data, BIM files and light data files available on request
