Table lamp CURVE THROUGH
metalpainted metalglass

Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 2
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 3
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 4
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 5
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 6
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 7
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 8
Table lamp - CURVE THROUGH - ZERO - metal / painted metal / glass - image - 9
Add to favorites
Compare this product
Go to the ZERO website for more information

Characteristics

Type
table
Material
metal, painted metal, glass, acrylic, opal
Style
contemporary
Power source
wireless
Location
indoor
Market
home, commercial
Base type
straight
Diffuser shape
round
Protection class
IP20
Color
white, blue, green, ivory
Light source
LED
Number of lights
single
Other characteristics
dimmable
Height

Min.: 432 mm
(17 in)

Max.: 640 mm
(25.2 in)

Description

Finish
Shades and stands in painted metal. Shades in glass are available in green or opal white. Diffuser in matt acrylic.

LED info
System power 8W. Luminaire luminous flux 170 lm – 765 lm depending on model. CCT 3000K. SDCM 3. CRI >90. L80 B10 50,000 h.

Installation
Fixed through-table mounting. Recommended cut-out Ø20 mm – Ø50 mm.

Connection
2.5 m cable with plug. Dimmable with external trailing-edge dimmer. Integrated switch on mounting plate available on request. Separate outlet matching the fixture available on request.

Classification
IP20.

Design
Front Design 2019.

Standard colours
Green, White, Pigeon blue, Ivory, other colours on request.

Product specification
POWER | D/mm | H/mm | Model | Color base | Shade | ART.
8W/170LM | 150 | 432 | S | Green | Green glass | 16008112-30
8W/332LM | 200 | 455 | S | Green | Green glass | 16008312-30
8W/415LM | 300 | 504 | S | Green | Green glass | 16008512-30
8W/170LM | 150 | 568 | L | Green | Green glass | 16010112-30
8W/332LM | 200 | 590 | L | Green | Green glass | 16010312-30
8W/415LM | 300 | 640 | L | Green | Green glass | 16010512-30
8W/465LM | 150 | 432 | S | White | White glass | 16008121-30
8W/606LM | 200 | 455 | S | White | White glass | 16008321-30
8W/765LM | 300 | 504 | S | White | White glass | 16008521-30
8W/465LM | 150 | 568 | L | White | White glass | 16010121-30
8W/606LM | 200 | 590 | L | White | White glass | 16010321-30
8W/765LM | 300 | 640 | L | White | White glass | 16010521-30
8W/138LM | 150 | 432 | S | White | White metal | 16009101-30
8W/337LM | 200 | 455 | S | White | White metal | 16009301-30
8W/476LM | 300 | 504 | S | White | White metal | 16009501-30
8W/138LM | 150 | 568 | L | White | White metal | 16011101-30
8W/337LM | 200 | 590 | L | White | White metal | 16011301-30
8W/476LM | 300 | 640 | L | White | White metal | 16011501-30
8W/138LM | 150 | 432 | S | Green | Green metal | 16009112-30
8W/337LM | 200 | 455 | S | Green | Green metal | 16009312-30
8W/476LM | 300 | 504 | S | Green | Green metal | 16009512-30
8W/138LM | 150 | 568 | L | Green | Green metal | 16011112-30
8W/337LM | 200 | 590 | L | Green | Green metal | 16011312-30
8W/476LM | 300 | 640 | L | Green | Green metal | 16011512-30
8W/138LM | 150 | 432 | S | Pigeon blue | Pigeon blue | 16009108-30
8W/337LM | 200 | 455 | S | Pigeon blue | Pigeon blue | 16009308-30
8W/476LM | 300 | 504 | S | Pigeon blue | Pigeon blue | 16009508-30
8W/138LM | 150 | 568 | L | Pigeon blue | Pigeon blue | 16011108-30
8W/337LM | 200 | 590 | L | Pigeon blue | Pigeon blue | 16011308-30
8W/476LM | 300 | 640 | L | Pigeon blue | Pigeon blue | 16011508-30
8W/138LM | 150 | 432 | S | Ivory | Ivory | 16009146-30
8W/337LM | 200 | 455 | S | Ivory | Ivory | 16009346-30
8W/476LM | 300 | 504 | S | Ivory | Ivory | 16009546-30
8W/138LM | 150 | 568 | L | Ivory | Ivory | 16011146-30
8W/337LM | 200 | 590 | L | Ivory | Ivory | 16011346-30
8W/476LM | 300 | 604 | L | Ivory | Ivory | 16011546-30

Recessed electrical outlets (Artplug)
Artplug 60 | Outlet: Plug socket/USB/USB C | Colour: Black | ART.: EAP-BLK-60
Artplug 60 | Outlet: Plug socket/USB/USB C | Colour: White | ART.: EAP-WHT-60
Artplug 54 | Outlet: Plug socket | Colour: Black | ART.: EAP-BLK-54TF
Artplug 54 | Outlet: Plug socket | Colour: White | ART.: EAP-WHT-54TF
Artplug 54U | Outlet: USB/USB C | Colour: Black | ART.: EAP-BLK-54U
Artplug 54U | Outlet: USB/USB C | Colour: White | ART.: EAP-WHT-54U

Technical characteristics / specifications
  • System power: 8W for all listed models.
  • Luminaire luminous flux: 170 lm up to 765 lm depending on model/size.
  • CCT: 3000K.
  • SDCM: 3.
  • CRI: >90.
  • Lifespan: L80 B10 at 50,000 h.
  • Ingress protection: IP20.
  • Mounting: Fixed through table-top; recommended cut-out Ø20 mm – Ø50 mm.
  • Connection: 2.5 m cable with plug; dimmable with external trailing-edge dimmer; integrated switch or separate outlet available on request.
  • Diffuser: matt acrylic. Shades: glass (green or opal white) or metal finishes per table.
  • Design: Front Design 2019.
  • Sizes and configurations: Models S and L with diameters 150 / 200 / 300 mm and varying heights as specified in the product specification table (see article numbers above).
