Modern ceiling light LOUD

cylindricalpainted steelLED

Product description
Architectural pendant luminaire for general and accent lighting. Shade and tube in painted steel. Available in downlight version with micro-prismatic diffuser and painted glare reduction grid, or in uplight version with matt acrylic diffuser. Fixed pendant length up to 1000 mm as standard; custom lengths available on request.

LED info
System power 25W. Luminaire luminous flux 1500 lm (downlight) to 2670 lm (uplight) depending on configuration. CCT 3000K. SDCM 3. CRI >80 standard, CRI >90 available on request. Lumen maintenance L80 B10 at 72,000 h.

Installation
Fixed pendant installation from ceiling. Supplied with painted ceiling cup.

Connection
Terminal block located in the ceiling cup for electrical connection.

Classification
IP20.

Design
Design by Adam Palm 2025.

Standard colours
White standard; other colours available on request.

Product specification
POWER/LUMEN | KELVIN | CRI | COLOUR | MODEL | CONTROL | ART.
25W/1500LM | 3000K | >80 | White | Downlight | On/off | 12400101-30
25W/1500LM | 3000K | >80 | White | Downlight | DALI/SwitchDim | 12400101D30
25W/1500LM | 3000K | >80 | Black | Downlight | On/off | 12400106-30
25W/1500LM | 3000K | >80 | Black | Downlight | DALI/SwitchDim | 12400106D30
25W/1500LM | 3000K | >80 | Brown | Downlight | On/off | 12400145-30
25W/1500LM | 3000K | >80 | Brown | Downlight | DALI/SwitchDim | 12400145D30
25W/2670LM | 3000K | >80 | White | Uplight | On/off | 12401101-30
25W/2670LM | 3000K | >80 | White | Uplight | DALI/SwitchDim | 12401101D30
25W/2670LM | 3000K | >80 | Black | Uplight | On/off | 12401106-30
25W/2670LM | 3000K | >80 | Black | Uplight | DALI/SwitchDim | 12401106D30
25W/2670LM | 3000K | >80 | Brown | Uplight | On/off | 12401145-30
25W/2670LM | 3000K | >80 | Brown | Uplight | DALI/SwitchDim | 12401145D30

Caractéristiques / spécifications techniques

• Shade material: painted steel.
• Tube material: painted steel.
• Downlight: micro-prismatic diffuser and painted glare reduction grid.
• Uplight: matt acrylic diffuser.
• Fixed pendant length: up to 1000 mm standard; custom lengths on request.
• LED system power: 25 W.
• Luminous flux: 1500 lm (downlight) to 2670 lm (uplight) depending on model.
• CCT: 3000 K.
• SDCM: 3.
• CRI: >80 standard, >90 on request.
• Lumen maintenance: L80 B10 at 72,000 h.
• Controls: On/Off standard; DALI / SwitchDim options available.
• Ingress protection: IP20.
• Installation: fixed pendant from ceiling with painted ceiling cup.
• Connection: terminal block in ceiling cup.
• Design: Adam Palm 2025.
• Standard colour: White (other colours available on request).
• Article numbers: see product specification table above.
