IP66 floodlight JNFL-ATEX-MODELF

ATEXexplosion-proofLED

Short description
Available mounting method: wall mounting. Hinged access door for maintenance. Supplied with 3/4” NPT or M25 conduit hubs. Label content can be customized (labels in various languages and with different exit signs are available).

Product Specifications
Product SKU: JNFL-ATEX-ModelF
Power Consumption: 20–200 W
Input Voltage: AC 120–277 V, 50/60 Hz; DC 36 V
Light Color: 2200–7000 K
LED Type: SMD
Total Lumens Output: 2600–26000 lm
Luminous Efficacy: 140 lm/W
Power Factor: >0.95
IK Impact Rating: IK07 (without wire guard); IK09 (with wire guard)
Housing Colour: Grey
Housing Material: Copper-free aluminium, tempered glass
Warranty Period: 5 years
IP Rating: IP66
Color Rendering Index (CRI): >70
Beam Angles: 40°, 60°, 90°, 120°
Dimming Capability: Non-dimmable
Certifications: ATEX (Ex db/eb/tb IIB/IIC, T6…T4), IECEx, UL (Class I/II) — see specifications for full classifications
Fixture Shape: Rectangular
Dimensions (HxWxL): 103 × 270 × 380 mm
Net Weight: 4.4 kg
Operating Temperature: -20°C to +45°C
Operating Humidity: 10–95% RH
Lifespan: 80,000 hours

Packaging & Shipping
Product Dimensions (mm): 103×270×380 mm
Net Weight (kg): 4.4 kg
Export Carton Dimensions (mm): 386×330×220 mm
Products per Carton: 1
Export Carton Gross Weight (kg): 14.5 kg

Technical features

• Power: 20–200 W
• Input Voltage: AC 120–277 V, 50/60 Hz; DC 36 V
• Lumens: 2600–26000 lm
• Efficacy: 140 lm/W
• IP Rating: IP66
• CRI: >70
• Beam Angles: 40°, 60°, 90°, 120°
• Dimming: Non-dimmable
• Warranty: 5 years
• Lifespan: 80,000 hours
• Net Weight: 4.4 kg
• Fixture dimensions (HxWxL): 103 × 270 × 380 mm
• Operating temperature: -20°C to +45°C
• Certifications: ATEX/IECEx/UL — see product specifications for full classes (flame-proof, dust-proof and temperature/gas group ratings)
