IP65 floodlight JNHM1-450S-3000-A3-ND
LEDoutdoorpole-mounted

IP65 floodlight - JNHM1-450S-3000-A3-ND - JNLED - LED / outdoor / pole-mounted
IP65 floodlight - JNHM1-450S-3000-A3-ND - JNLED - LED / outdoor / pole-mounted
IP65 floodlight - JNHM1-450S-3000-A3-ND - JNLED - LED / outdoor / pole-mounted - image - 2
Add to favorites
Compare this product

Characteristics

Protection class
IP65
Light source
LED
Interior/exterior use
outdoor
Type
pole-mounted
Shape
rectangular
Dimmable
not dimmable
Other characteristics
IK08
Height

Max.: 854 mm
(34 in)

Min.: 854 mm
(34 in)

Length

Max.: 610 mm
(24 in)

Min.: 610 mm
(24 in)

Width

Max.: 238 mm
(9 in)

Min.: 238 mm
(9 in)

Power

Max.: 450 W
(0.61 hp)

Min.: 450 W
(0.61 hp)

Luminous flux

Max.: 63,500 lm

Min.: 63,500 lm

Color temperature

Max.: 3,000 K

Min.: 3,000 K

Color rendering index (CRI)

Max.: 100 unit

Min.: 70 unit

Description

Short description
450 Watt LED flood light with original Philips Lumileds and Meanwell driver(s). Non-dimmable. IP65. Replaces 100 Watt metal halide/HID/HPS.

Product Specifications
Product SKU: JNHM1-450S-3000-A3-ND
Power Consumption: 450 W
Input Voltage: 120-277 V AC (347~488 V optional)
Beam Angle: 40°x140° (Type III fixed)
IP Rating: IP65
Color Rendering Index (CRI): >70
LED Type: Philips Lumileds
Color Temperature: 3000 K
IK Rating: IK08
Dimming: Non-dimmable
Housing Colour: Marine-Grey
Warranty Period: 5 years
Power Factor: >0.95
Surge Protection: 10 kV
Input Cable: H07RN-F 3G1.0
Operating Temperature: -20°C to 45°C
Operating Humidity: 10%–95% RH
Lifespan: 80,000 hours
Total Lumens Output: 63,500 lm
Efficacy: 140 lm/W
System Power: 495 W
Number of LED Modules: 4 modules
LED Driver Brand: Meanwell HLG-480H
Lens Material: Tempered Glass
Fixture Dimensions (H×L×W): 854 × 610 × 238 mm
Net Weight: 30 kg

Packaging & Shipping
Net Weight (kg): 30 kg
Export Carton Dimensions (mm): 900×700×320 mm
Products per Carton: 2
Export Carton Gross Weight: 34 kg
Fixture Height (mm): 854
Fixture Width (mm): 238
Fixture Length (mm): 610

Technical specifications
  • Product SKU: JNHM1-450S-3000-A3-ND
  • Power Consumption: 450 W
  • Input Voltage: 120-277 V
  • Beam Angle: 40° / 40°x140° (Fixed)
  • IP Rating: IP65
  • CRI: >70
  • LED Type: Philips Lumileds
  • Colour Temperature: 3000 K
  • IK Rating: IK08
  • Dimming: Non-dimmable
  • Housing Colour: Marine-Grey
  • Warranty: 5 years
  • Power Factor: >0.95
  • Surge Protection: 10 kV
  • Input Cable: H07RN-F 3G1.0
  • Working Temperature Range: -20°C ~ 45°C
  • Working Humidity Range: 10%-95% RH
  • Lifespan: 80,000 hours
  • Number of LED Modules: 4 modules
  • LED Driver: Meanwell HLG-480H
  • Lens Material: Tempered Glass
  • System Power: 495 W
  • Input Voltage Range (optional): 347~488V AC
  • Fixture Dimensions (H×L×W): 854 mm × 610 mm × 238 mm
  • Total Lumens Output: 63,500 lm
  • Efficacy: 140 lm/W
  • Net Weight: 30 kg
  • Export Carton Dimensions: 900×700×320 mm
  • Products per Carton: 2
  • Export Carton Gross Weight: 34 kg
