IP65 floodlight JNHM1-450S-4000-A2-DIM

LEDroadoutdoor

Product Short Description
450 Watt LED floodlight for high-mast applications, equipped with Philips Lumileds and Meanwell HLG-480H drivers. Dimmable (0-10V). IP65 rated for outdoor use. Beam distribution 50°x140° (Type II) suitable for roadway and area illumination. Total system power 495 W with 63,500 lm output and 140 lm/W efficacy.

Product Specifications
Product SKU: JNHM1-450S-4000-A2-DIM
Power Consumption: 450 W (System Power 495 W)
Input Voltage: 120-277 V AC (347~488 V AC optional)
Beam Angle: 50°x140° (Type II, fixed)
IP Rating: IP65
Color Temperature: 4000 K
Color Rendering Index (CRI): >70
LED Type: Philips Lumileds
LED Driver: Meanwell HLG-480H (dimmable 0-10V)
Lens Material: Tempered Glass
IK Rating: IK08
Power Factor: >0.95
Surge Protection: 10 kV
Operating Temperature: -20°C to 45°C
Operating Humidity: 10%–95% RH
Lifespan: 80,000 hours (L70)
Total Lumen Output: 63,500 lm
Efficacy: 140 lm/W
Fixture Dimensions (HxLxW): 854 × 610 × 238 mm
Weight (Net): 30 kg

Packaging & Shipping
Export Carton Dimensions: 900 × 700 × 320 mm
Products per Carton: 2
Export Carton Gross Weight: 34 kg
Net Weight per Fixture: 30 kg
Fixture Dimensions (mm): H 854 × L 610 × W 238

Technical Features

• SKU: JNHM1-450S-4000-A2-DIM
• Power Consumption: 450 W
• Input Voltage: 120-277 V AC (347~488 V AC optional)
• Beam Angle: 50°x140° (Type II)
• IP Rating: IP65
• CRI: >70
• LED: Philips Lumileds
• Color Temperature: 4000 K
• IK Rating: IK08
• Dimming: 0-10V
• Housing Colour: Marine-Grey
• Warranty: 5 years
• Power Factor: >0.95
• Surge Protection: 10 kV
• Input Cable: H07RN-F 3G1.0
• Operating Temperature: -20°C ~ 45°C
• Operating Humidity: 10%–95% RH
• Lifespan: 80,000 hours
• Beam Angle Range: 50°x140° (Fixed)
• Beam Type: Type II
• Number of LED Modules: 4
• LED Driver Brand: Meanwell HLG-480H
• Lens Material: Tempered Glass
• System Power: 495 W
• Input Voltage Range: 120-277 V AC / 347~488 V AC (optional)
• Fixture Height: 854 mm
• Fixture Length: 610 mm
• Fixture Width: 238 mm
• Total Lumens: 63,500 lm
• Efficacy: 140 lm/W
