IP65 floodlight JNFLM12-100S-5000-A6-DIMLEDoutdoorsurface-mounted
Add to favorites
Compare this product
Characteristics
- Protection class
- IP65
- Light source
- LED
- Interior/exterior use
- outdoor
- Type
- surface-mounted
- Shape
- rectangular
- Dimmable
- dimmable
- Other characteristics
- adjustable, IK08
- Height
Min.: 113 mm
(4 in)Max.: 113 mm
(4 in)- Length
Min.: 326 mm
(13 in)Max.: 326 mm
(13 in)- Width
Min.: 128 mm
(5 in)Max.: 128 mm
(5 in)- Power
Min.: 100 W
(0.14 hp)Max.: 100 W
(0.14 hp)- Luminous flux
Min.: 13,000 lm
Max.: 13,000 lm
- Color temperature
Min.: 6,000 K
Max.: 6,000 K
- Color rendering index (CRI)
Min.: 80 unit
Max.: 100 unit
Description
Overview
A 100W cool white modular LED flood light designed for outdoor applications. It delivers high lumen output in a compact modular form factor and is suitable as a retrofit replacement for 250W metal halide/HID/HPS luminaires.
Highlights
Technical specifications
A 100W cool white modular LED flood light designed for outdoor applications. It delivers high lumen output in a compact modular form factor and is suitable as a retrofit replacement for 250W metal halide/HID/HPS luminaires.
Highlights
- Modular 1×2 module configuration
- Cool white (6000 K), high output (13000 lm)
- Dimmable with Meanwell driver(s)
- Durable outdoor rating: IP65 and IK08
Technical specifications
- Product SKU: JNFLM12-100S-5000-A6-DIM
- Power Consumption: 100 W
- System Power: 106 W
- Input Voltage: 100-277 V
- Input Frequency: 50/60 Hz
- Beam Angle: 40×100° (Beam Angle Square: 40×100°)
- Total Lumens Output: 13000 lm
- Colour Temperature: 6000 K
- Colour Rendering Index (CRI): >80
- LED Type: Philips Lumileds (Luxeon TX)
- LED Driver Brand: Meanwell driver(s)
- Dimming Capability: Dimmable
- Power Factor: >0.95
- IP Rating: IP65
- IK Impact Rating: IK08
- Housing Material: Die-cast Aluminum
- Housing Colour: Black
- Mounting Type: Adjustable Bracket Mount
- Fixture Height: 113 mm
- Fixture Length: 326 mm
- Fixture Width: 128 mm
- Product Dimensions (mm): 326×128×113 mm
- Product Weight / Net Weight: 6 kg
- Export Carton Dimensions (mm): 400×360×230 mm
- Products per Carton: 1
- Export Carton Gross Weight (kg): 8 kg
- Environmental / Working Temperature Range: -20°C ~ 45°C
- Working Humidity Range: 10% - 90% RH
- Lifespan: 50,000 hours
- Warranty Period: 5 years
- Number of LED Modules: 1 module
