IP65 floodlight JNFLM18/6-400S-5000-A1-DIM
LEDindustrialfor stadium

IP65 floodlight - JNFLM18/6-400S-5000-A1-DIM - JNLED - LED / industrial / for stadium
IP65 floodlight - JNFLM18/6-400S-5000-A1-DIM - JNLED - LED / industrial / for stadium
Add to favorites
Compare this product
Go to the JNLED website for more information

Characteristics

Protection class
IP65
Light source
LED
Application
industrial, for stadium, for parking lot, for airport
Interior/exterior use
outdoor
Type
surface-mounted
Shape
square
Beam type
spot
Dimmable
dimmable
Other characteristics
high-efficiency, adjustable, energy-saving, IK08
Height

Max.: 113 mm
(4 in)

Min.: 113 mm
(4 in)

Length

Max.: 326 mm
(13 in)

Min.: 326 mm
(13 in)

Width

Max.: 128 mm
(5 in)

Min.: 128 mm
(5 in)

Power

Max.: 406 W
(0.55 hp)

Min.: 400 W
(0.54 hp)

Luminous flux

Max.: 52,000 lm

Min.: 52,000 lm

Color temperature

Max.: 6,000 K

Min.: 6,000 K

Color rendering index (CRI)

Max.: 100 unit

Min.: 80 unit

Description

Product description
400W modular LED flood light in a 1×6 module configuration. Equipped with original Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Dimmable, IP65 and IK08 rated, die-cast aluminium housing in black. Designed to replace 1000W metal halide/HID fixtures while delivering 52,000 lm at 6000K (cool white). Suitable for outdoor industrial and commercial lighting with adjustable bracket mounting.

Key features
  • Modular design (1×6 modules)
  • Original Philips Lumileds (Luxeon TX) LEDs
  • Meanwell LED driver(s), dimmable
  • IP65 ingress protection
  • IK08 impact rating
  • Die-cast aluminium housing, black
  • Total luminous flux: 52,000 lm
  • Color temperature: 6000 K (cool white)
  • Long lifespan: 50,000 hours


Technical specifications
  • SKU: JNFLM18/6-400S-5000-A1-DIM
  • Power consumption: 400 W (system power 406 W)
  • Input voltage: 100–277 V
  • Input frequency: 50/60 Hz
  • Beam angle: 15×15° (square)
  • LED type: Philips Lumileds (Luxeon TX)
  • Total lumen output: 52,000 lm
  • Color temperature: 6000 K
  • Color rendering index (CRI): >80
  • Power factor: >0.95
  • Dimming capability: Dimmable (Meanwell driver(s))
  • IP rating: IP65
  • IK impact rating: IK08
  • Housing material: Die-cast aluminium, black
  • Mounting: Adjustable bracket mount
  • Dimensions (L×W×H): 326 × 128 × 113 mm
  • Product weight: 17.2 kg
  • Operating temperature: -20°C to 45°C
  • Operating humidity: 10%–90% RH
  • Lifespan: 50,000 hours
  • Warranty: 5 years
  • Number of LED modules: 1 module (1×6 configuration)


Applications
  • Industrial yards, warehouses and logistics centres
  • Sports facilities and stadiums
  • Building façades and architectural lighting
  • Ports, docks and shipyards
  • Airport apron and outdoor ramp lighting
  • Outdoor signage and perimeter lighting


Packaging & Shipping
  • Product dimensions (mm): 326 × 128 × 113
  • Net weight: 17.2 kg
  • Export carton dimensions (mm): 400 × 360 × 230
  • Products per carton: 1
  • Export carton gross weight: 8 kg


Compliance & warranty
  • Ingress protection IP65 and impact rating IK08
  • Warranty period: 5 years
