IP65 floodlight JNFLM20-600S-6500-A5-ND

LEDindustrialoutdoor

Product overview
600 W modular LED flood light in a 2×4 module configuration. Equipped with Philips Lumileds (Luxeon TX) LEDs and Meanwell driver(s). Listed on the page as non-dimmable; see note about dimming capability below. IP65 ingress protection and IK08 impact rating for outdoor industrial use. Beam angle 30×100°, cool white 6000 K, total luminous flux 78,000 lm. Die-cast aluminum housing in black with adjustable bracket mount. Input voltage 100-277 V, power factor >0.95, system power 606 W, lifespan approx. 50,000 hours.

Product specifications (as listed on page)
Product SKU: JNFLM20-600S-6500-A5-ND
Power Consumption: 600 W
System Power: 606 W
Input Voltage: 100-277 V, 50/60 Hz
Beam Angle (°): 30x100°
IP Rating: IP65
IK Impact Rating: IK08
LED Type: Philips Lumileds (Luxeon TX)
LED Driver Brand: Meanwell driver(s)
Total Lumens Output: 78,000 lm
Color Temperature (K): 6000 K
Color Rendering Index: >80
Power Factor: >0.95
Dimming Capability: Dimmable
Housing Material: Die-cast Aluminum
Housing Colour: Black
Mounting Type: Adjustable Bracket Mount
Fixture Dimensions (mm): 326 × 128 × 113
Product Weight: 17.2 kg
Operating Temperature Range: -20°C to 45°C
Operating Humidity Range: 10%–90% RH
Lifespan (Hours): 50,000 hours
Warranty Period (Years): 5

Packaging & Shipping
Product Dimensions (mm): 326 × 128 × 113
Net Weight (kg): 17.2
Export Carton Dimensions (mm): 400 × 360 × 230
Products per Carton: 1
Export Carton Gross Weight (kg): 8

Note
The page title and short description indicate "Non-dimmable" while the specifications table lists "Dimmable" for dimming capability; both statements are preserved here exactly as presented on the page.

Technical specifications

• SKU: JNFLM20-600S-6500-A5-ND
• Power consumption: 600 W (System Power: 606 W)
• LEDs: Philips Lumileds (Luxeon TX)
• Driver: Meanwell driver(s)
• Lumens: 78,000 lm
• Colour temperature: 6000 K
• CRI: >80
• Beam angle: 30×100°
• IP rating: IP65
• IK rating: IK08
• Power factor: >0.95
• Input voltage: 100-277 V, 50/60 Hz
• Housing: Die-cast aluminum, colour: Black
• Mounting: Adjustable bracket mount
• Dimensions (mm): 326 × 128 × 113
• Weight: 17.2 kg
• Operating temperature: -20°C to 45°C
• Operating humidity: 10%–90% RH
• Lifespan: 50,000 hours
• Warranty: 5 years
